Main Features

• Effective Resolution: 16-bit
• Channel: 8-channel difference
• Input Type: mV, V, mA
• Input Range: ±150mV, ±500mV, ±5V, ±10V, 0-20mA, 4-20 mA
• Digital Output: Channels - 2, Open Collector 30V, 100mA Max Load
• Power Consumption: 2W

Main Specifications

• Isolation Voltage: 2000VDC
• Malfunction and Overload Protection: Max Voltage: ± 35V
• Sampling Rate: 10MS/s
• Input Impedance: 20MΩ
• Bandwidth: 13.1Hz@50Hz 15.72Hz@60Hz
